High Strength Calcium Silicate Board 270kg/m³ (1100°C)

High strength calcium silicate board is mainly composed of xonotlite (6CaO·6SiO₂·H₂O), offering excellent thermal resistance and mechanical strength compared with conventional insulation materials.

With higher density and improved structural performance, this product maintains stability even under high temperature conditions. Minimal crystal water loss ensures no structural damage during operation.

It is widely used in industrial furnaces, steel plants, and high-temperature insulation systems requiring higher strength and durability.

Applications

Industrial furnaces

Steel and metallurgy industry

Petrochemical equipment

High temperature structural insulation

Heavy-duty thermal insulation systems

Key Features

  • Non-asbestos, safe and environmentally friendly
  • High mechanical strength with 270kg/m³ density
  • Continuous service temperature up to 1050°C
  • Low thermal conductivity at all temperature ranges
  • Excellent durability without powdering
  • Free from harmful substances (no sulfur, chlorine)
  • Suitable for heavy-duty industrial insulation applications

Specifications

SiO₂
≥55%
CaO
≥36%
Al₂O₃
≤0.5%
Fe₂O₃
≤0.5%
Bulk Density
270 (±10%)kg/m³
Compressive Strength
≥1.5MPa
Flexural Strength
≥1.0MPa
Continuous Service Temp
≤1050°C
Max Service Temp °C
≤1050°C
Linear Shrinkage
≤2% (1000°C, 16h)
Thermal Conductivity 20°C
≤0.059(W/m·K)
200°C
≤0.075(W/m·K)
400°C
≤0.092(W/m·K)
600°C
≤0.120(W/m·K)
800°C
≤0.149(W/m·K)
