Ultra High Strength Calcium Silicate Board 400kg/m³ (1100°C)

Ultra high strength calcium silicate board is manufactured from xonotlite (6CaO·6SiO₂·H₂O), offering exceptional thermal resistance and superior mechanical performance.

With an ultra-high density of 400kg/m³, this board provides outstanding load-bearing capacity and structural stability under extreme high-temperature conditions. Even at elevated temperatures, minimal crystal water loss ensures long-term durability without structural damage.

It is specially designed for heavy-duty industrial applications requiring maximum strength and high temperature resistance.

Key Features

✓Non-asbestos, safe and environmentally friendly
✓Ultra high density (400kg/m³) for maximum strength
✓Maximum service temperature up to 1100°C
✓Excellent load-bearing and structural performance
✓Low thermal conductivity across all temperature ranges
✓Long service life without powdering
✓Free from harmful substances (no sulfur, chlorine)

Specifications

SiO₂

≥52%

CaO

≥40%

Al₂O₃

≤0.3%

Fe₂O₃

≤1.0%

Bulk Density

400 (±10%)kg/m³

Compressive Strength

≥4.0MPa

Flexural Strength

≥1.8MPa

Continuous Service Temp

≤1050°C

Max Service Temp

≤1100°C

Linear Shrinkage

≤2% (1000°C, 16h)

Thermal Conductivity 20°C

≤0.068(W/m·K)

200°C

≤0.087(W/m·K)

400°C

≤0.113(W/m·K)

600°C

≤0.139(W/m·K)

800°C

≤0.170(W/m·K)
